DETECTOR CAREVIEW 1500L CABLE

 Especificaciones
 Sensor
 Scintillator  CsI Direct Deposit
 Active Area  433.7 x 354.8 mm2 (14″x17″)
 Pixel Array  2816X2304
 Pixel Pitch  154 μm
 Image Quality
 Limiting Resolution  3.3Ip/mm
 Dynamic Range  > 80 dB
 Greyscale  16 bits
 Communication Interface
 Communication Interface  GbitE
 Image Acquisition Time  2-3s
 Exposure Control  F2AED
 Manual
 External Trigger
 Environmental
 Operating  Natural Cooling
 Temperature Range  5℃-35℃ (41℉-95℉)
  Humidity Range(Non-condensing)  30%-75%RH
 Storage
 Temperature Range  -20℃-55℃ (-4℉-67℉)
 Humidity Range  10%-90% RH
 Mechanical
 Dimension  460x384x15mm3 (18″x15″x0.6″)
 Weight  3.2Kg (7lbs)
 Housing Material  Carbon fiber front
 High Strength aluminium alloy back
 Power
 Power Dissipation  <8W (standby) 20W (operating)
 Power Supply  100-240V AC
 Frequency  50/60Hz
